Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Type Power Management
Function Phase Control
Embedded Yes, MCU, 8-Bit
Utilized IC / Part ST7FLITEU5Y0B6
Primary Attributes Light Dimmer and Motor Speed Control
Supplied Contents Board(s)
Secondary Attributes Selectable Button or Potentiometer Controlled
Other Names 497-5515
Standard Package 1
MSL Level 2A (4 Weeks)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284493-STEVAL-ILL004V2
Ultra Librarian 3D Model Ultra Librarian STEVAL-ILL004V2 CAD Model

Description

STEVAL-ILL004V2 - LED Driver Evaluation Board by STMicroelectronics

The STEVAL-ILL004V2 is a highly efficient evaluation board designed by STMicroelectronics, tailored for driving LEDs with advanced features to enhance performance in various lighting applications. This board is part of ST's extensive range of evaluation tools, which are intended to provide designers with the most effective solutions for their LED lighting designs.

At the heart of the STEVAL-ILL004V2 is an LED driver that operates with a wide input voltage range, making it suitable for a variety of power supply conditions. This flexibility ensures that it can be used in multiple geographical regions without the need for significant alterations to accommodate different mains voltages.

The board is designed to drive a string of LEDs with a maximum output voltage of up to 50V, and it can support an output current of up to 350mA. This current can be adjusted if necessary, providing designers with the ability to fine-tune the brightness levels of their LED setups to match specific requirements. Additionally, the driver includes features such as overcurrent protection, thermal shutdown, and overvoltage protection to ensure the longevity and reliability of both the LEDs and the driver itself.

The STEVAL-ILL004V2 is also characterized by its high efficiency, which not only reduces energy consumption but also minimizes the amount of heat generated, thereby extending the lifespan of the LEDs. The board's layout is optimized to ensure good thermal management, which is crucial in maintaining performance levels over time.

Ease of use is another key feature of the STEVAL-ILL004V2. The board comes with a comprehensive set of documentation, including schematics, bill of materials, and application notes, which streamline the development process for engineers. Whether for industrial lighting, architectural lighting, or even advanced consumer lighting solutions, the STEVAL-ILL004V2 is an excellent starting point for developing sophisticated and reliable LED systems.

In summary, the STEVAL-ILL004V2 from STMicroelectronics is a versatile and high-performance solution for LED driving applications that demand efficiency, reliability, and user-friendliness.
