STEVAL-IPM07F - Compact Motor Drive System from STMicroelectronics

The STEVAL-IPM07F is an advanced motor drive system designed by STMicroelectronics, specifically tailored for applications requiring high efficiency, compact size, and robust performance. This integrated power module is part of the SLLIMM™-nano series and is an excellent choice for driving motors in a variety of applications including home appliances, fans, pumps, and other low-power motor control scenarios.

Key Features


• Integrated Design: The module integrates a gate driver and two power MOSFETs in a single, compact package, simplifying the design and reducing the overall footprint on the PCB.

• High-Efficiency Operation: With its advanced MOSFET technology, the STEVAL-IPM07F ensures low conduction and switching losses, leading to high efficiency in motor drive applications.

• Wide Voltage Range: The module is designed to operate over a wide range of input voltages, accommodating various power supply specifications.

• Overcurrent Protection: Built-in overcurrent protection safeguards the module and the motor from potential damage caused by excessive current conditions.

• Under-Voltage Lockout: The under-voltage lockout feature ensures that the module operates within safe voltage levels, protecting both the circuit and the motor.

• Thermal Shutdown: An integrated thermal shutdown function provides additional protection by turning off the module if the temperature exceeds safe operating limits.


Applications


• Home Appliances

• Ceiling and Portable Fans

• Small Pumps

• General Low-Power Motor Drives


The STEVAL-IPM07F is an exemplary solution for designers looking to enhance the performance of their motor drive systems while reducing development time and cost. Its integrated features and protections ensure a reliable and efficient operation, making it an ideal choice for a wide range of motor control applications. STMicroelectronics' commitment to quality and performance is evident in this innovative motor drive module.
