Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Series VIPER™
Package Box
Main Purpose AC/DC, Primary Side
Outputs and Type 1, Isolated
Power - Output 10 W
Voltage - Output 5V
Current - Output 2A
Voltage - Input 90 ~ 265 VAC
Regulator Topology Flyback
Frequency - Switching 60kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part VIPer28
Base Product Number STEVAL
Other Names 497-14883,-497-14883
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284176-STEVAL-ISA125V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA125V1 CAD Model

Description

The STEVAL-ISA125V1 from STMicroelectronics is a state-of-the-art evaluation board designed for testing and measuring the performance of the L7987, a high-efficiency DC-DC converter. This product is an excellent tool for engineers and developers who require a reliable and flexible platform to experiment with and optimize their power supply designs.

Key Features

  • Wide Input Voltage Range: The board operates over an input voltage range from 4.5 V to 38 V, making it suitable for a variety of applications, including industrial and automotive systems.
  • Adjustable Output Voltage: Users can adjust the output voltage from 0.8 V to VIN, providing flexibility for different design requirements.
  • High Output Current: The L7987 can deliver up to 3 A of output current, which is ideal for powering a wide range of electronic loads.
  • High Efficiency: The device features a peak efficiency of 95%, ensuring minimal power loss and heat generation during operation.
  • Protection Features: The board includes various protection mechanisms such as overcurrent protection, thermal shutdown, and overvoltage protection, enhancing the reliability of the end application.
  • Easy-to-use: The evaluation board comes with pre-mounted components and test points, making it user-friendly for immediate setup and testing.

Applications

The versatility of the STEVAL-ISA125V1 makes it suitable for a broad range of applications, including:

  • Industrial power supplies
  • Automotive applications
  • Consumer electronics
  • Telecommunication systems
  • Embedded systems

Why Choose the STEVAL-ISA125V1?

With its robust design, comprehensive feature set, and high level of performance, the STEVAL-ISA125V1 is an ideal choice for professionals seeking a reliable and versatile evaluation platform. Whether you are developing power supplies for industrial equipment or consumer electronics, this evaluation board from STMicroelectronics offers a convenient and efficient solution for your power management needs.
