Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Active
Core Processor ARM Cortex-M3
Part Core Size 32-Bit
Speed(Frequency) 36MHz
Number of I/O 80
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
Data RAM Size 32K x 8
Supply Voltage - Operating 2 V to 3.6 V
Data Converters A/D 16x12b, D/A 2x12b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 100-LQFP (14x14)
Win Source Part Number 031269-STM32F101VCT6
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STM32F101VCT6 CAD Model

Description

STM32F101VCT6 Microcontroller

The STM32F101VCT6 is a high-performance ARM Cortex-M3 based microcontroller from STMicroelectronics, designed to offer a balanced combination of computing power, reduced power consumption, and innovative peripherals. This microcontroller is part of the STM32F1 series, which is renowned for its robust design and reliability, making it an ideal choice for a wide range of applications including industrial control, medical equipment, and consumer electronics.

With a maximum CPU frequency of 36 MHz, the STM32F101VCT6 can handle complex tasks while maintaining energy efficiency. The device features a 256 KB flash memory and 48 KB of SRAM, providing ample space for application code and data storage. The microcontroller's memory architecture also includes an extensive range of DMA channels, which significantly improves the overall system performance by offloading data transfer tasks from the CPU.

The rich set of peripherals integrated into the STM32F101VCT6 includes multiple 16-bit timers, an advanced-control PWM timer for motor control, and up to 37 GPIOs that offer various digital interface options. The device supports several communication interfaces such as I2C, SPI, USART, and CAN, enabling it to easily communicate with other devices and form the backbone of complex embedded systems.

Furthermore, the STM32F101VCT6 comes with an array of analog features, including 12-bit ADCs and DACs, which are essential for interfacing with sensors and other analog components. The microcontroller's robustness is further enhanced by its wide operating voltage range (from 2.0 to 3.6 volts) and its temperature range, making it suitable for demanding environments.

For security and system integrity, the STM32F101VCT6 incorporates a flexible memory protection unit (MPU) and a set of system functions managed by the Nested Vectored Interrupt Controller (NVIC), which ensures quick and efficient handling of interrupts. The microcontroller also offers various low-power modes, which are crucial for battery-operated devices, where power conservation is a priority.

In summary, the STM32F101VCT6 is a versatile and powerful microcontroller that provides a scalable choice for designers who require a cost-effective solution with a rich peripheral set and high system integration.
