Products specifications

Category Integrated Circuits (ICs)>Embedded - Microcontrollers
Mfr STMicroelectronics
Series STM32H7
Package Tray
Core Processor ARM® Cortex®-M4/M7
Core Size 32-Bit Dual-Core
Speed 240MHz, 480MHz
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Number of I/O 148
Program Memory Size 2MB (2M x 8)
Program Memory Type FLASH
RAM Size 1M x 8
Supply Voltage - Operating 1.62V ~ 3.6V
Data Converters A/D 32x16b; D/A 2x12b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 208-LQFP
Supplier Device Package 208-LQFP (28x28)
Base Product Number STM32
Standard Package 360
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
HTSUS 0000.00.0000
Win Source Part Number 1262586-STM32H757BIT6
Ultra Librarian 3D Model Ultra Librarian STM32H757BIT6 CAD Model

Description

The STM32H757BIT6 is a state-of-the-art microcontroller unit (MCU) from STMicroelectronics, designed for high-performance applications that require a balance of power efficiency and processing capability. This MCU is part of the STM32H7 series, which is renowned for its advanced architecture, rich set of peripherals, and high-speed interfacing capabilities.

Key Features

  • Advanced Core: The STM32H757BIT6 is equipped with a dual-core configuration featuring an ARM® Cortex®-M7 core running at up to 480 MHz and a Cortex®-M4 core at up to 240 MHz. This dual-core architecture allows for efficient task separation and optimal performance.
  • Memory: It includes 2 Mbytes of Flash memory and 1 Mbyte of RAM, providing ample space for complex applications and the flexibility for sophisticated memory management.
  • Rich Connectivity: The MCU offers a wide range of connectivity options, including USB OTG, Ethernet, CAN, UART, SPI, I2C, and more, enabling it to handle various communication protocols with ease.
  • Graphics Support: With its Chrom-ART Accelerator™, the STM32H757BIT6 enhances graphic operations, making it an ideal choice for applications with user interfaces that require rich graphics and smooth animation.
  • Power Efficiency: The MCU is designed with energy efficiency in mind, featuring multiple power-saving modes to ensure optimal consumption for battery-powered or energy-sensitive applications.
  • Analog Features: It includes advanced analog peripherals such as ADCs, DACs, and operational amplifiers, catering to applications that require precise analog signal management.
  • Development Support: STMicroelectronics provides extensive development support for the STM32H757BIT6, including software libraries, development boards, and a comprehensive Integrated Development Environment (IDE) ecosystem.

Applications

The versatility of the STM32H757BIT6 allows it to be used in a wide array of applications, from industrial control systems to medical devices, from advanced robotics to complex IoT devices. Its high processing power and rich set of features make it particularly well-suited for applications that require significant computational resources alongside real-time responsiveness.

Overall, the STM32H757BIT6 represents a powerful and flexible solution for developers looking to create sophisticated and high-performance embedded systems.
