Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 770mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 4μA @ 100V
Mounting SMD (SMT)
Case / Package STmite Flat
Operating Temperature - Junction 175°C (Max)
Win Source Part Number 031497-STPS1H100MF
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian STPS1H100MF CAD Model

Description

STPS1H100MF - Schottky Rectifier by STMicroelectronics

The STPS1H100MF is a robust and high-performance Schottky rectifier designed by STMicroelectronics, a leader in the semiconductor industry. This rectifier is specifically engineered to cater to a wide range of applications, including switch-mode power supplies, converters, free-wheeling diodes, and reverse battery protection. Its low forward voltage drop and high current capability make it an ideal choice for high-efficiency power management tasks.

Key Features

  • High Junction Temperature Capability: The STPS1H100MF can operate at junction temperatures as high as 150°C, making it suitable for use in high-temperature environments.
  • Low Forward Voltage Drop: With a low forward voltage drop, this rectifier ensures minimal power loss during conduction, enhancing the overall efficiency of the application it is used in.
  • High Surge Current Capability: The device is capable of withstanding high surge currents, which is critical for applications that experience transient overcurrent conditions.
  • Robust Package: Enclosed in a Microflat package, the STPS1H100MF offers a compact footprint and excellent power density. This package is designed for surface mount applications and provides good thermal resistance.
  • Avalanche Rated: This Schottky rectifier is capable of handling energy in avalanche mode, which is an added protection feature for demanding scenarios.

Applications

  • Switch-mode power supplies (SMPS)
  • DC-DC converters
  • Automotive applications
  • Free-wheeling diodes in power circuits
  • Reverse battery protection

The STPS1H100MF is a testament to STMicroelectronics' commitment to providing high-quality, reliable components for the electronics industry. Its combination of high-temperature operation, low power loss, and compact packaging makes it an excellent choice for designers looking to optimize their power management systems. Whether it's for industrial, automotive, or consumer applications, the STPS1H100MF Schottky rectifier is designed to meet the demands of modern electronic circuits.
