Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 100V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Maximum) at If 960mV at 4A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1μA at 100V
Mounting Style SMD
Manufacturer Package SOD-123F
Supplier Device Package SOD-123F
Operating Temperature - Junction -40°C ~ 175°C
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1261886-STPS2H100ZF
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian STPS2H100ZF CAD Model

Description

The STPS2H100ZF is a robust power Schottky rectifier designed by STMicroelectronics, a leader in semiconductor solutions. This component is engineered to offer low forward voltage drop while ensuring high surge current capability, which is crucial for a wide range of applications including switching power supplies, converters, and free-wheeling diodes in consumer and industrial devices.

Key Features

  • Average Forward Current: The device is capable of handling an average forward current of 2 A, making it suitable for medium power applications.
  • Repetitive Peak Reverse Voltage: With a repetitive peak reverse voltage of 100 V, the STPS2H100ZF provides a good safety margin for most low to medium voltage applications.
  • Low Forward Voltage Drop: The low forward voltage drop (typically 0.82 V at 2 A) enhances overall system efficiency by reducing power loss during operation.
  • High Junction Temperature: The device can operate at junction temperatures ranging from -40°C to 175°C, offering reliable performance even under extreme conditions.
  • Package: The STPS2H100ZF comes in a surface-mount SMBflat package, which is designed to optimize board space and improve thermal performance.

Applications

The STPS2H100ZF is versatile and can be used in a variety of applications, including:

  • Switching power supplies
  • DC-DC converters
  • Free-wheeling diodes in various applications
  • Power management solutions
  • Reverse voltage protection circuits

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STPS2H100ZF is no exception and is manufactured to meet the stringent standards for performance and reliability that customers expect from STMicroelectronics. With its advanced manufacturing process and rigorous testing, the STPS2H100ZF is a reliable choice for designers looking to enhance the efficiency and longevity of their electronic systems.
