Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 150V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 840mV @ 30A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 20μA @ 150V
Operating Temperature - Junction 175°C (Max)
Mounting Through Hole
Case / Package TO-247-3
Win Source Part Number 088324-STPS61150CW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name STPS61150CW
Introduction Date November 25, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian STPS61150CW CAD Model

Description

STPS61150CW Power Schottky Rectifier by STMicroelectronics

The STPS61150CW is a state-of-the-art power Schottky rectifier designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is part of the STPS61 series and is encapsulated in a robust and compact TO-247 package, engineered to provide high-efficiency power management in a wide range of applications.

With a repetitive peak reverse voltage (V<sub>RRM) of 150V and an average forward current (I<sub>F(AV)) of 60A, the STPS61150CW is optimized for high-performance operations. It features a high junction temperature capability, which ensures reliability and stability even under extreme conditions. The low forward voltage drop (V<sub>F) characteristic of Schottky diodes contributes to its efficiency, reducing thermal losses and improving the overall system performance.

The device's high surge current capability makes it an excellent choice for applications requiring robustness against transient conditions. Its fast switching behavior is ideal for high-frequency operations, making it suitable for use in switch-mode power supplies (SMPS), converters, freewheeling diodes, and reverse battery protection circuits.

The STPS61150CW also exhibits low leakage current, which enhances its performance in low-power applications and contributes to energy savings. This feature, combined with its high efficiency, makes it an environmentally friendly choice for power management solutions.

Engineers and designers will appreciate the STPS61150CW for its ease of integration into various circuit designs due to its industry-standard TO-247 package. This ensures compatibility with a wide range of heatsinks and simplifies the thermal management of the device.

In summary, the STPS61150CW power Schottky rectifier from STMicroelectronics is a reliable, efficient, and versatile component that meets the demands of modern power management systems. Its robust design and superior electrical characteristics make it an indispensable part of any high-performance power conversion and management solution.
