The TIP36C is a silicon Power Transistor manufactured by STMicroelectronics, a global semiconductor leader. This transistor is part of a series of PNP epitaxial silicon transistors designed for use in power linear and switching applications. It is widely recognized for its high power dissipation capabilities, making it suitable for a wide range of electronic circuits.

Key Features

• PNP Transistor: The TIP36C is a PNP transistor, which means it is turned on or off by the movement of holes across a junction, providing an efficient current flow in the opposite direction to NPN transistors.
• High Power Dissipation: With a power dissipation of 125W, the TIP36C can handle significant power, making it ideal for high-power applications.
• High Collector-Emitter Voltage: It can withstand a collector-emitter voltage (VCEO) of up to 100V, providing a good safety margin for many electronic applications.
• High Current Capacity: The TIP36C has a collector current rating of up to 25A, ensuring it can support circuits with high current demands.
• Complementary NPN Type: The complementary NPN type is TIP35C, allowing for easy implementation in push-pull configurations.

Applications

The TIP36C is versatile and can be used in various applications, including:

• Power regulators
• Audio amplifiers
• Switching circuits
• Motor control systems

Quality and Reliability

STMicroelectronics is known for its commitment to quality and reliability, and the TIP36C is no exception. It is built to meet the stringent requirements of the electronics industry, providing a reliable solution for power management challenges.

Environmental Compliance

The TIP36C also meets various environmental standards, reflecting STMicroelectronics' dedication to sustainability and environmental responsibility.
