Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type Current Sense
Number of Circuits 1
Slew Rate 0.9 V/μs
-3db Bandwidth 450kHz
Current - Input Bias 5.5μA
Voltage - Input Offset 200μV
Operating Supply Current 165μA
Channel Output Current 60mA
Supply Voltage - Operating 4 V to 24 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 035281-TSC101CILT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSC101CILT CAD Model

Description

STMicroelectronics TSC101CILT High-Side Current Sense Amplifier

The TSC101CILT from STMicroelectronics is a precision high-side current sense amplifier designed to monitor the current flow in power supply systems and industrial applications. This integrated circuit (IC) amplifies the small voltage drop across a shunt resistor placed in the path of the high-side power supply rail, enabling accurate current measurement without disrupting the ground path of the load.

Featuring a wide input common-mode voltage range from 2.8V to 30V, the TSC101CILT is suitable for a variety of applications, including battery management systems, overcurrent protection, and power management solutions. The device's ability to operate over a broad voltage range allows it to be used in both low and high voltage systems, providing flexibility for designers.

The TSC101CILT offers a fixed gain of 20V/V, which simplifies the design process by eliminating the need for external gain-setting components. This fixed gain ensures a stable and predictable amplification of the differential voltage across the shunt resistor, translating into reliable current measurement. The low input offset voltage of the amplifier minimizes error in current sensing, thereby enhancing the accuracy of the system.

Engineered with precision in mind, the TSC101CILT boasts a low quiescent current, which is ideal for power-sensitive applications. The low current consumption helps to reduce overall power loss and improves system efficiency. Additionally, the device comes in a small SOT23-5 package, making it an excellent choice for space-constrained applications where PCB real estate is at a premium.

The TSC101CILT also includes a wide operating temperature range from -40°C to +125°C, ensuring reliable performance in harsh environments. This temperature range makes the IC well-suited for automotive and industrial applications where temperature extremes are common.

In summary, the TSC101CILT by STMicroelectronics is a robust, precise, and versatile high-side current sense amplifier that provides designers with a simple and efficient solution for current monitoring in a wide array of applications.
