Products specifications

Category Integrated Circuits (ICs) - Power Management (PMIC) - Current Regulation/Management
Mfr STMicroelectronics
Package Tape & Reel
Function Current Sense
Sensing Method High-Side
Voltage - Input 4V ~ 28V
Mounting Type Surface Mount
Package / Case 36-PowerFSOP (0.295", 7.50mm Width)
Supplier Device Package PowerSSO-36
Base Product Number VN7000
Standard Package 1,000
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1339762-VN7000AYTR
Ultra Librarian 3D Model Ultra Librarian VN7000AYTR CAD Model

Description

The VN7000AYTR is a cutting-edge high-side driver manufactured by STMicroelectronics, a leader in semiconductor solutions. This device is part of the VIPower M0-7 series and is specifically designed to address the needs of automotive applications requiring high-power load management.

Key Features

  • High Voltage Capability: The VN7000AYTR is capable of handling a wide range of operating voltages, making it suitable for various automotive electrical systems.
  • Current Control: With its precision current control, it ensures consistent performance and protection for connected loads.
  • Thermal Shutdown: The device includes a thermal shutdown feature to prevent overheating, safeguarding both the driver and the system it controls.
  • Load Dump Protection: It is designed to withstand voltage transients in the automotive environment, providing load dump protection that is crucial for vehicle electronics.
  • Diagnostic Functions: Integrated diagnostics capabilities allow for monitoring and feedback of the system status, enhancing reliability and safety.

Applications

The VN7000AYTR is ideal for various high-power automotive applications, including:

  • Engine Control Units (ECUs)
  • Body Control Modules (BCMs)
  • Automotive Lighting Systems
  • Power Distribution Systems

Product Specifications

The VN7000AYTR comes in a compact and robust PowerSSO-16 package, ensuring reliable performance even in harsh automotive environments. Its low on-resistance and high ESD immunity make it an excellent choice for driving high-current loads with efficiency and precision.

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The VN7000AYTR is designed with the stringent requirements of the automotive industry in mind, meeting ISO 26262 standards for functional safety and AEC-Q100 qualification for automotive-grade reliability.

Whether you are designing modern vehicles or upgrading existing automotive systems, the VN7000AYTR from STMicroelectronics provides a robust and reliable solution for high-side driving applications.
