Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Power Distribution Switches, Load Drivers
Mfr STMicroelectronics
Series VIPower™
Package Tube
Product Status Active
Switch Type General Purpose
Number of Outputs 1
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Voltage - Load 5.5V ~ 36V
Voltage - Supply (Vcc/Vdd) Not Required
Current - Output (Max) 2.5A
Rds On (Typ) 60mOhm
Input Type Non-Inverting
Features Auto Restart, Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package PPAK
Package / Case TO-252-5, DPak (4 Leads + Tab), TO-252AD
Base Product Number VN751
Standard Package 75 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 696848-VN751PT
Ultra Librarian 3D Model Ultra Librarian VN751PT CAD Model

Description

The VN751PT is a high-performance automotive-grade single-channel high-side driver manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is part of the VIPower family and is designed to drive automotive applications with advanced smart power technology.

With an operating voltage range from 5.5V to 36V, the VN751PT is suitable for 12V automotive systems, and it is capable of withstanding voltage transients up to 40V. The device ensures a high level of reliability and robustness, which is essential for the demanding automotive environment.

The VN751PT integrates various diagnostic features, including open-load detection in the off-state, short-circuit to Vcc, thermal shutdown, and overcurrent protection. These features enhance the safety and reliability of the system by providing real-time feedback in case of fault conditions.

This high-side driver also features a current-controlled input, which reduces the power dissipation and allows direct drive through a microcontroller. Moreover, the VN751PT is equipped with a current limitation function to prevent damage from overcurrent conditions, and a status feedback pin that indicates the state of the output load.

The device comes in a compact and thermally efficient PowerSSO-10 package, which is suitable for space-constrained applications. Its package is designed to optimize the thermal dissipation and ensure a lower junction temperature, thus improving the overall lifetime and reliability of the device.

STMicroelectronics' VN751PT is a testament to their commitment to providing high-quality and innovative products for the automotive industry. With its advanced protection features, diagnostic capabilities, and high power efficiency, the VN751PT is an ideal solution for driving resistive, inductive, or capacitive loads, such as lamps, solenoids, or motors in modern vehicles.
