The TD1583P is a 3A, 23V, 500KHz step-down converter from Techcode. It's designed for applications requiring efficient power conversion in a compact footprint. Its integrated power MOSFET and synchronous rectifier contribute to high efficiency and minimal external components.
Applications:
- Point-of-Load Regulators: Provides a stable and efficient voltage supply for individual components or subsystems.
- Power Tools: Used in portable power tools requiring efficient step-down conversion.
- Consumer Electronics: Powering devices such as set-top boxes, LCD monitors, and portable media players.
- Network Equipment: Supplies power to network devices such as routers and switches.
- FPGA, DSP and MCU supplies.
Features:
- High Efficiency: Achieved through synchronous rectification.
- Adjustable Output Voltage: Allows for tailoring the output voltage to specific application requirements.
- Over-Current Protection: Protects the device and downstream components from over-current conditions.
- Over-Temperature Protection: Prevents thermal damage to the device.
- Input Voltage Range: Up to 23V: Suitable for many industrial applications.
- 3A Continuous Output Current: High current capability for powering various loads.
Benefits:
- Improved Battery Life: High efficiency minimizes power loss, extending battery life in portable applications.
- Reduced Component Count: Integrated features reduce the need for external components, simplifying the design process.
- Enhanced System Reliability: Protection features ensure stable and reliable operation.
- Compact Solution: Small footprint enables use in space-constrained applications.
- Thermal Performance: Built for environments where heat dissipation needs to be managed properly.
Additional Details:
The TD1583P features a fixed switching frequency of 500kHz, which allows for the use of smaller external components. It incorporates an internal compensation network, further simplifying the design process. The device also includes short-circuit protection and thermal shutdown. Available in ESOP-8 package.
