Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Supply Voltage - Operating 3 V to 18 V
Current - Quiescent (Max) 4μA
Current - Output High, Low 3.4mA, 3.4mA
Logic Level - Low 0.9 V to 4 V
Logic Level - High 3.6 V to 10.8 V
Max Propagation Delay @ V, Max CL 120ns @ 15V, 50pF
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 14-PDIP
Dimension 14-DIP (0.300", 7.62mm)
Win Source Part Number 006149-CD40106BE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Clock & Timing, Consumer Electronics, Embedded Design & Development, Multimedia
Family Name CD40106
Introduction Date January 01, 2002
ECCN EAR99
Country of Origin Malaysia, Mexico
Halogen Free Not Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian CD40106BE CAD Model

Description

The CD40106BE is a through-hole mounted variant in the CD40106 series, making it perfect for breadboarding and prototyping work as well as more permanent installations where component replacement is a consideration. Its robust performance under a broad range of conditions ensures credible outcomes in complex circuits.

Features and Benefits

  • Compatible with standard breadboards
  • Wide voltage range adaptability (3V to 15V)
  • High immunity to noise
  • Static discharge protection exceeding 4000V

Applications

  • Educational electronics projects
  • Delay circuits
  • Integrated signal processing
  • Automated test equipment

The CD40106BE stands out because of its ease of use in prototyping environments, offering flexibility and reliability for both learning and professional development activities.
