Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Type Sensor Conditioner
Input Type Logic
Output Type Logic
Operating Supply Current 6.8mA
Operating Temperature Range -55°C ~ 125°C
Mounting SMD
Package 20-SOIC (0.295", 7.50mm Width) Exposed Pad
Manufacturer Package 20-SO PowerPad
Win Source Part Number 1168562-DRV401AMDWPREP
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name DRV401-EP
Introduction Date May 01, 2008
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian DRV401AMDWPREP CAD Model

Description

The DRV401AMDWPREP is a high-precision, integrated circuit from Texas Instruments designed for industrial applications that require accurate current sensing and control. This advanced product is part of TI's reliable line of signal conditioning solutions and is ideal for motor control, power management, and protection systems where efficiency and reliability are critical.

Key features of the DRV401AMDWPREP include:

  • Integrated Current Shunt Amplifier: The device comes with a precision amplifier that is optimized for low voltage drop across shunts, which translates to minimal power loss and enhanced efficiency.
  • Advanced Modulation Techniques: It utilizes a modulation/demodulation technique that reduces the effects of interference, thereby improving signal integrity and accuracy in noisy industrial environments.
  • Adjustable Gain: The gain of the current shunt amplifier can be adjusted, offering flexibility in various application requirements and allowing for precise current measurement across a wide range of shunt resistor values.
  • Wide Operating Temperature Range: With an operating temperature range from -55°C to +125°C, the DRV401AMDWPREP is designed to withstand harsh conditions and maintain performance in extreme environments.
  • Robust Packaging: The device is available in a 16-pin SOIC package with a PowerPAD™ for enhanced thermal performance, ensuring reliable operation even under high power or high ambient temperature conditions.

The DRV401AMDWPREP also features a demodulator output for coil current sensing, which is highly beneficial for applications that utilize solenoids or transformers. It offers excellent linearity and temperature stability, which is crucial for systems that demand precise control and monitoring.

Designed with the end-user in mind, the DRV401AMDWPREP is easy to integrate into existing designs due to its straightforward pin configuration and compatibility with standard SPI communication interfaces. Whether it's used in automated factory equipment, robotics, or renewable energy systems, the DRV401AMDWPREP from Texas Instruments is your go-to solution for reliable and accurate current sensing applications.
