F10 Raltron Electronics Corporation
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr XP Power
Series XP EMCO - F (10W)
Package Bulk
Product Status Active
Type High Voltage - Isolated Module
Number of Outputs 1
Voltage - Input (Min) 0.7V
Voltage - Input (Max) 12V
Voltage - Output 1 1000V
Current - Output (Max) 10mA
Power (Watts) 10 W
Voltage - Isolation 3.5 kV
Applications ITE (Commercial)
Features Proportional Output
Temperature Range - Operating -10°C ~ 70°C
Mounting Type Through Hole
Package / Case 5-DIP Module
Size / Dimension 2.80" L x 1.70" W x 0.85" H (71.1mm x 43.2mm x 21.6mm)
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 590378-F10
Ultra Librarian 3D Model Ultra Librarian F10 CAD Model

Description

The XP EMCO - F (10W) series from XP Power is a range of high voltage isolated modules. These modules feature proportional output and come in a bulk package.

  • Size: 2.80" L x 1.70" W x 0.85" H (71.1mm x 43.2mm x 21.6mm)
  • Application: ITE (Commercial)
  • Power Rating: 10W
  • Voltage Isolation: 3.5 kV
  • Output: Single
  • Maximum Output Current: 10mA
  • Temperature Range: -10°C to 70°C
