EPCS1SI8N Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Altera
Packaging Tube/Rail
Programmable Type In System Programmable
Memory Size 1Mb
Supply Voltage - Operating 2.7 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Case / Package 8-SOIC
Win Source Part Number 015528-EPCS1SI8N
Family Name EPCS1
Introduction Date February 08, 2005
ECCN 3A991.b.1.b.1
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian EPCS1SI8N CAD Model

Description

EPCS1SI8N Serial Configuration Device

The EPCS1SI8N combines flexibility and reliability to provide excellent configuration storage for FPGA systems. Its 1 Mbit non-volatile memory in an 8-pin package caters to various electronic design needs.

  • Highly efficient memory utilization.
  • Designed for easy system upgrades.
  • Supports extensive operational lifespan.

Applications and Projects:

  • FPGA device configurations.
  • Commercial product development.
  • Embedded system enhancements.
  • Secure data logging systems.

It delivers outstanding performance for projects requiring dependable and efficient configuration solutions.
