SMBJ16CA Bytes
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Bytes
Win Source Part Number 1251465-SMBJ16CA
Manufacturer Homepage 0
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Imaging, Video & Vision, Industrial
Family Name SMBJ16CA
Introduction Date December 26, 2000
ECCN EAR99
Country of Origin China
Estimated EOL Date 2024
Package Cut Tape (CT)
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 16V
Voltage - Breakdown (Min) 17.8V
Voltage - Clamping (Max) @ Ipp 26V
Current - Peak Pulse (10/1000µs) 23.1A
Power - Peak Pulse 600W
Power Line Protection No
Applications General Purpose
Operating Temperature -65°C ~ 150°C (TJ)
Grade -
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB
Package Tape & Reel (TR)
Supplier Device Package DO-214AA (SMB)
Ultra Librarian 3D Model Ultra Librarian SMBJ16CA CAD Model

Description

The Bytes SMBJ16CA is a popular electronic component used in communications and networking, computers and computer peripherals, imaging, video and vision, and industrial applications.

  • Manufacturer: Bytes
  • Product Name: SMBJ16CA
  • Family Name: SMBJ16CA
  • Estimated EOL Date: 2024
  • Introduction Date: December 26, 2000
  • ECCN: EAR99
  • Country of Origin: China
  • RoHS State: Request verification
