MBR3545 GeneSiC Semiconductor
Same model may have multiple batches, images only for reference.

MBR3545

Part No MBR3545
Manufacturer GeneSiC Semiconductor
Catalog Diodes, Rectifiers - Single
Description 35 Amp Rectifier 20 to 100 Volts Schottky Barrier | DIODE SCHOTTKY 45V 35A DO4
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 45V
Current - Average Rectified (Io) 35A
Voltage - Forward (Vf) (Maximum) at If 680mV at 35A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1.5mA at 20V
Mounting Style Chassis, Stud Mount
Manufacturer Package DO-203AA, DO-4, Stud
Supplier Device Package DO-4
Operating Temperature - Junction -55°C ~ 150°C
Manufacturer Pack Quantity 250
MSL Level 1 (Unlimited)
Win Source Part Number 1216131-MBR3545
Manufacturer Homepage www.mccsemi.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MBR3545 CAD Model

Description

The 1216131-MBR3545 is a Schottky diode manufactured by GeneSiC Semiconductor with a peak reverse voltage of 45V and an average rectified current of 35A.

  • Peak Reverse Voltage: 45V
  • Average Rectified Current: 35A
  • Package: Chassis, stud mount
  • Recovery Speed: 200mA (Io)
  • Temperature Range: -55°C to 150°C
  • Forward Voltage: 680mV @ 35A
  • Device Package: DO-4
  • Current Reverse Leakage @ Vr: 1.5mA @ 20V
  • Manufacturer Pack Quantity: 250
  • MSL Level: 1 (Unlimited)
  • Supply and Demand Status: Limited
