Products specifications Report Issue?

Manufacturer Integrated Circuit Systems
Win Source Part Number 1183590-ICS552AR-01LF
Manufacturer Homepage www.icst.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ICS552AR-01LF CAD Model

Description

The ICS552AR-01LF is a zero delay buffer (ZDB) clock driver manufactured by Integrated Circuit Systems (ICS). It's designed to distribute a clock signal with minimal delay and skew, ensuring accurate timing synchronization in high-speed digital systems. This device is often used to drive multiple loads from a single clock source, while maintaining signal integrity.

Applications

  • Motherboards.
  • Graphics cards.
  • Networking equipment.
  • Servers.
  • High-speed digital circuits.
  • Clock distribution networks.

Features

  • Zero delay buffer: Minimizes delay between input and output clocks.
  • Multiple outputs: Drives multiple loads from a single clock source.
  • Low skew: Maintains tight timing synchronization between outputs.
  • Low jitter: Minimizes phase noise in the output clock signals.
  • 3.3V operation: Compatible with modern low-voltage logic systems.
  • Lead-free packaging: Environmentally friendly design.

Benefits

  • Improved timing synchronization: Zero delay and low skew ensure accurate timing in high-speed systems.
  • Increased system performance: Minimized clock skew improves system stability and performance.
  • Simplified clock distribution: Multiple outputs simplify clock network design.
  • Reduced jitter: Low jitter clock signals improve signal integrity.

Additional Details

The ICS552AR-01LF operates with a 3.3V supply voltage. The device is designed to minimize the delay between the input clock and the output clocks. The low skew ensures that all output clocks arrive at their destinations at approximately the same time. The operating temperature range is typically from 0°C to +70°C (commercial grade). Consult the datasheet for specific parameters such as output clock frequency, skew specifications, and jitter performance.
