Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - FPGAs (Field Programmable Gate Array)
Mfr Intel
Series Cyclone® V E
Package Tray
Number of LABs/CLBs 9434
Number of Logic Elements/Cells 25000
Total RAM Bits 2002944
Number of I/O 224
Voltage - Supply 1.07V ~ 1.13V
Mounting SMD (SMT)
Temperature Range - Operating 0°C ~ 85°C (TJ)
Package / Case 484-BGA
Supplier Device Package 484-FBGA (23x23)
Base Product Number 5CEFA2
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Other Names 544-3153,965943,5CEFA2F23C6N-ND
Standard Package 60
Win Source Part Number 997538-5CEFA2F23C6N
Ultra Librarian 3D Model Ultra Librarian 5CEFA2F23C6N CAD Model

Description

The Cyclone® V E is a highly efficient integrated circuit that is used in various electronic devices.

  • Win Source Part Number: 997538-5CEFA2F23C6N
  • Category: Embedded - FPGAs (Field Programmable Gate Array)
  • Design: Has a unique design that makes it stand out from other integrated circuits.
  • I/O: 224
  • LABs/CLBs: 9434
  • Logic Elements/Cells: 25000
  • Manufacturer: Intel
  • Package: 484-BGA
