The LT1782CS5 is a high-performance operational amplifier from Linear Technology, designed to offer precision with low power consumption. Its rail-to-rail input and output capabilities make it an ideal choice for a wide range of applications, including battery-powered devices, portable instrumentation, and test equipment.

Key Features

• Rail-to-Rail Input and Output: The LT1782CS5 can operate with input and output signals that extend to both supply rails. This feature allows for greater flexibility in single-supply applications and maximizes the dynamic range.
• Low Power Consumption: With a supply current of just 20µA per amplifier, the LT1782CS5 is optimized for low-power applications, helping to extend battery life in portable devices.
• Wide Supply Range: The device operates from a supply voltage range of 2.5V to 12.6V, accommodating various power environments and allowing for use in both 3V and 5V systems.
• Precision Performance: The LT1782CS5 offers excellent DC accuracy, with an input offset voltage of only 375µV and input bias current of 1nA, making it suitable for precision measurement and control systems.
• High Output Drive: Capable of driving loads as low as 600 ohms, this op amp can handle a wide array of output demands.
• Temperature Range: The device is specified for operation from -40°C to 85°C, ensuring reliable performance across a broad range of environmental conditions.

Applications

• Portable and battery-powered equipment
• Test and measurement devices
• Sensor amplifiers
• Data acquisition systems
• Medical instrumentation
• Low voltage signal processing

The LT1782CS5 is offered in the compact 5-lead SOT-23 package, making it well-suited for space-constrained applications. Its combination of precision, low power, and small footprint makes it an excellent choice for designers looking to optimize their systems for both performance and size.
