Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology/Analog Devices
Packaging Reel
Output Type Adjustable
Voltage - Input (Maximum) 23V
Min/Fixed Output Voltage 0V
Maximum Output Voltage 23V
Maximum Dropout Voltage 0.51V at 3A
Output Current 3A
Current - Quiescent (Iq) 50.5μA
Maximum Supply Current 1mA
PSRR 85dB ~ 20dB (120Hz ~ 1MHz)
Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Supplier Device Package 5-DDPAK
Family Part Number LT3083
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 719122-LT3083EQ#TRPBF
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT3083EQ#TRPBF CAD Model

Description

The LT3083EQ#TRPBF is a versatile low dropout linear regulator from Linear Technology, designed to provide precision current and voltage control with a wide input voltage range. It is an innovative device that uses a single resistor to set the output current from 0 to 3A, making it a flexible solution for various applications.

Key Features:

  • Adjustable Output: The output voltage is adjustable down to 0V, with a single resistor setting the output current, providing design flexibility for a wide range of applications.
  • Wide Input Voltage Range: Capable of operating with an input voltage range from 1.1V to 36V, the LT3083EQ#TRPBF is suitable for applications with varying input supplies.
  • Stable with Low ESR Capacitors: The device remains stable with ceramic, tantalum, or aluminum electrolytic capacitors, eliminating the need for specific types or values of output capacitors.
  • Low Dropout Voltage: The regulator features a low dropout voltage, ensuring efficient operation even when the input and output voltages are close to each other.
  • Protection Features: It includes built-in protection features such as current limiting, thermal shutdown, and reverse battery protection, safeguarding the device and the application under adverse conditions.

Applications:

  • Power Supplies
  • Battery-Powered Equipment
  • Automotive Electronics
  • Industrial Controls
  • Telecommunications Infrastructure

The LT3083EQ#TRPBF is presented in a 5-lead TO-263 package, which is designed for high power applications that require efficient heat dissipation. The regulator's precision and reliability make it an ideal choice for designers looking for a robust power management solution. With its ease of use and comprehensive feature set, the LT3083EQ#TRPBF is a valuable component for any power regulation task that demands high performance and adaptability.
