Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Purpose Step-Up
Topology Boost, Charge Pump
Output Type Adjustable
Number of Outputs 2
Minimum Input Voltage 2.4V
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) ±1.25V
Maximum Output Voltage ±40V
Output Current 180mA (Switch), 320mA (Switch)
Synchronous Rectifier No
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 111167-LT3463EDD#TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LT3463
Introduction Date November 20, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT3463EDD#TRPBF CAD Model

Description

Product Overview: LT3463EDD#TRPBF

The LT3463EDD#TRPBF is a high-performance, micropower step-up DC/DC converter designed and manufactured by Linear Technology. This compact and efficient power management IC is specifically engineered to meet the needs of battery-powered and low-voltage systems. Its small form factor and high-efficiency operation make it an ideal choice for portable devices, medical equipment, and other applications where space and power are at a premium.

Key Features

  • Wide Input Voltage Range: Capable of operating from a 1.2V to 15V input, the LT3463EDD#TRPBF is versatile enough to be used with a variety of power sources, including single-cell batteries.
  • Adjustable Output Voltage: The output voltage is adjustable up to 40V, allowing for flexibility across different applications.
  • High Efficiency: With its internal 1.3A power switch, the device can deliver efficiencies up to 90%.
  • Low Quiescent Current: The LT3463EDD#TRPBF boasts a low quiescent current of only 20µA, which is ideal for battery-powered applications where power conservation is critical.
  • Integrated Soft-Start Function: This feature limits inrush current during startup, providing a smoother power up and extending the life of the battery.
  • Thermal Protection: The device includes thermal shutdown protection to prevent damage from overheating.
  • Small Package: Housed in a 10-lead DFN package, the LT3463EDD#TRPBF saves precious board space and is suitable for compact circuit designs.

Applications

The LT3463EDD#TRPBF is an excellent choice for a wide range of applications, including:

  • Portable Electronic Devices
  • Photoflash Capacitor Chargers
  • Local Power Supplies
  • OLED Power Supplies
  • GPS and Wireless Communication Devices

In summary, the LT3463EDD#TRPBF from Linear Technology is a highly versatile and efficient solution for step-up voltage conversion in space-constrained and power-sensitive applications. Its wide input voltage range, adjustable output, and low power consumption make it a top choice for designers seeking to optimize their power management systems.
