Products specifications

Manufacturer Linear Technology
Win Source Part Number 1206779-LT3652IMSE
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT3652IMSE CAD Model

Description

The LT3652IMSE is a highly versatile power tracking 2A battery charger from Linear Technology, designed to provide efficient charging for a wide array of battery chemistries including lead-acid, Li-Ion, and LiFePO4. This advanced charging device is suitable for automotive, industrial, and portable applications where efficient power management is crucial.

Key Features

  • Input Voltage Range: The device operates over a wide input voltage range of 4.95V to 32V, making it flexible for various power supply conditions.
  • Adjustable Charging Rates: With the ability to deliver up to 2A of charge current, the LT3652IMSE can be programmed with a resistor to set the charge rate according to the specific needs of the application and battery chemistry.
  • Multi-Chemistry Charging: The charger is capable of handling different battery chemistries, which is essential for a broad range of applications.
  • Power Tracking: Its power tracking capability ensures optimal use of available input power, especially in scenarios with limited power like solar panels or wind energy systems.
  • Temperature Compensation: The charging parameters can be adjusted based on temperature inputs to maximize charging efficiency and battery life.
  • Integrated Safety Features: Includes protections such as overvoltage, undervoltage, overtemperature, and short-circuit protections to ensure safe and reliable operation.

Applications

The LT3652IMSE is ideal for a variety of applications, including:

  • Solar-Powered Systems
  • Electric Vehicles
  • Portable Handheld Devices
  • Uninterruptible Power Supplies (UPS)
  • Industrial Power Systems

Package and Quality

The LT3652IMSE is available in a 12-lead MSOP package, which is compact and suitable for space-constrained applications. Linear Technology ensures high-quality and reliability of their products, and the LT3652IMSE is no exception, adhering to stringent quality control standards.

With its advanced features and adaptability to various power sources and battery chemistries, the LT3652IMSE stands out as a robust solution for sophisticated battery charging applications.
