Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Applications Thermoelectric Cooler/Heater
Operating Supply Current 2mA
Operating Supply Voltage 2.7 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 28-SSOP (0.154", 3.90mm Width)
Manufacturer Package 28-SSOP
Win Source Part Number 782282-LTC1923EGN#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTC1923
Introduction Date June 03, 2002
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTC1923EGN#PBF CAD Model

Description

Product Overview: LTC1923EGN#PBF

The LTC1923EGN#PBF is a high-performance thermoelectric cooler (TEC) controller integrated circuit (IC) crafted by Linear Technology, which is now part of Analog Devices. This sophisticated component is designed to precisely control the temperature of laser diodes, CCDs, and other temperature-sensitive components by driving a thermoelectric cooler. The LTC1923EGN#PBF is housed in a 28-lead SSOP package and is characterized by its high efficiency and reliability.

Key Features

  • Precise Temperature Control: The device offers accurate control of the TEC, ensuring that the temperature of the application remains stable within the desired range. This is critical for applications requiring precise temperature regulation.
  • Efficient Operation: With its high efficiency, the LTC1923EGN#PBF minimizes power loss and ensures optimal operation of the TEC, leading to a longer lifespan and reduced energy costs.
  • Bidirectional Control: The controller can both heat and cool, allowing for bidirectional control of the thermoelectric cooler.
  • Integrated Features: The IC includes a digital PID (Proportional-Integral-Derivative) control loop, which provides a stable and responsive temperature control system.
  • Monitoring and Protection: It offers features such as voltage and current monitoring, as well as under- and over-temperature protection, ensuring the safety and durability of the application.
  • Wide Voltage Range: The device operates over a wide input voltage range, accommodating various power supplies and system requirements.

Applications

The LTC1923EGN#PBF is an ideal choice for a range of precision temperature control applications. It is commonly used in:

  • Fiber Optic Systems (to control the temperature of laser diodes)
  • Optical Networking Equipment
  • Medical Equipment (for temperature control of sensitive components)
  • Industrial Instrumentation
  • High-Performance CPU and GPU Cooling Systems

Conclusion

In summary, the LTC1923EGN#PBF from Linear Technology is a versatile and efficient solution for managing the temperature of critical components in a variety of high-tech applications. With its precise control, efficient operation, and robust protection features, this TEC controller is an invaluable component for ensuring the optimal performance and reliability of temperature-sensitive systems.
