The LTC2440IGN is a high precision analog-to-digital converter (ADC) from Linear Technology, which is now part of Analog Devices. This product is designed to offer exceptional performance with a 24-bit resolution that ensures high accuracy and low noise in measurement applications. It is an ideal choice for industrial, medical, and automotive systems where precise data conversion is critical.

Key Features

• Resolution: 24-bit with no missing codes
• Data Output Rate: Adjustable from 5Hz to 3.5kHz
• Input Type: Differential
• Supply Voltage: Single 5V operation
• Interface: SPI-compatible serial interface
• Package: 16-lead SSOP

Performance

The LTC2440IGN provides a high level of precision due to its oversampling sigma-delta technology, which also contributes to its excellent noise rejection capabilities. It offers a flexible output rate that can be adjusted according to the needs of the application, ensuring that users can balance between resolution and speed effectively.

Applications

With its robust feature set, the LTC2440IGN is suitable for a wide range of applications, including:

• High precision data acquisition systems
• Industrial process control
• Temperature measurements with RTDs or thermocouples
• Weigh scales
• Medical monitoring devices
• Automotive testing and diagnostics

Reliability and Quality

The LTC2440IGN is designed to meet the stringent requirements of industrial and automotive applications. It operates over a wide temperature range and is housed in a robust 16-lead SSOP package, ensuring it can withstand challenging environmental conditions while maintaining high performance.

Easy Integration

Integration of the LTC2440IGN into system designs is made easy thanks to its SPI-compatible serial interface, allowing for straightforward communication with microcontrollers and digital systems. Additionally, its single 5V supply voltage simplifies power management within the design.
