Products specifications

Manufacturer Linear Technology
Win Source Part Number 1208575-LTC2855CDE
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LTC2855CDE CAD Model

Description

LTC2855CDE - Robust Interface Transceiver from Linear Technology

The LTC2855CDE is a highly versatile and robust interface transceiver product from Linear Technology, designed to provide reliable communication in industrial and automotive environments. This transceiver is part of the LTC2855 series, which offers integrated features that enhance the performance and resilience of the standard RS485/RS422 communication protocols.

With a wide supply voltage range of 3V to 5.5V, the LTC2855CDE is suitable for a variety of applications, allowing it to be used in systems with different power supply requirements. The device supports data rates up to 20Mbps, making it an excellent choice for high-speed data transmission while maintaining signal integrity over long cable runs.

One of the standout features of the LTC2855CDE is its extended common-mode range of -7V to +12V, which exceeds the industry standard. This enables the transceiver to operate reliably in electrically noisy environments where ground potentials may vary significantly, such as in industrial automation systems or distributed control systems.

The LTC2855CDE also includes integrated protection features that safeguard the transceiver against harsh conditions. It is equipped with overvoltage protection on the receiver input and driver output to ±25V, ensuring that the device can handle direct shorts or transients without damage. Additionally, the device features a fail-safe receiver that guarantees a known output state when the inputs are open or shorted, thus preventing system lock-up or undefined states.

For design flexibility, the LTC2855CDE comes in a compact 12-lead DFN package (4mm x 3mm) with enhanced thermal performance, making it suitable for space-constrained applications that require efficient heat dissipation. Moreover, the transceiver is fully specified over the industrial temperature range of -40°C to +85°C, ensuring reliable operation in extreme temperature conditions.

In summary, the LTC2855CDE from Linear Technology is a feature-rich, high-speed interface transceiver that offers robust communication capabilities, extensive protection mechanisms, and a wide operating temperature range, making it an ideal solution for demanding industrial and automotive applications.
