Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Applications Power Supply Monitor
Voltage - Input 7 V to 80 V
Supply Voltage - Operating 7 V to 80 V
Operating Supply Current 1.2mA
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 10-MSOP
Win Source Part Number 110830-LTC4151IMS#TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LTC4151IMS#TRPBF CAD Model

Description

Linear Technology LTC4151IMS#TRPBF High Voltage I2C Current and Voltage Monitor

The LTC4151IMS#TRPBF is a sophisticated monitoring device from Linear Technology, designed to keep a vigilant eye on the current and voltage levels in high voltage systems. This high-performance chip is an essential component for applications that demand precise power monitoring to ensure operational safety and efficiency.

Key Features:

  • Wide Operating Range: The LTC4151IMS#TRPBF can monitor systems with a supply voltage range from 7V to 80V, making it versatile for a broad spectrum of high voltage applications.
  • High Side Measurement: High side current sensing allows for the detection of current flowing to the load, providing a safer and more accurate measurement environment, as it does not interfere with the ground path of the load.
  • I2C Interface: The device features an I2C interface for communication, allowing for easy integration with microcontrollers and other digital systems. This digital interface provides real-time current and voltage monitoring with programmable alert and charge complete outputs.
  • 12-Bit ADC: It comes equipped with a 12-bit analog-to-digital converter that ensures high precision in measurement readings.
  • Low Power Consumption: Designed for efficiency, the LTC4151IMS#TRPBF operates with a low quiescent current, making it suitable for power-sensitive applications.

Applications:

  • Telecommunications
  • Industrial Systems
  • Automotive Electronics
  • Datacom Infrastructure
  • Battery Management Systems

The LTC4151IMS#TRPBF is housed in an MSOP-10 package, which is compact and suitable for space-constrained applications. Its robust design ensures reliable performance even in harsh environments, and its high accuracy makes it an excellent choice for critical applications where monitoring the power supply is paramount.

Whether you're designing a sophisticated server farm, an automotive power system, or a sensitive piece of industrial machinery, the LTC4151IMS#TRPBF from Linear Technology offers the precision, reliability, and ease of use necessary to ensure your systems run smoothly and safely.
