Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 70mV
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 088883-LTC485CS8#TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC485CS8#TR CAD Model

Description

The LTC485CS8#TR is a low power differential bus/line transceiver designed by Linear Technology for RS485 and RS422 communications. This device is specifically engineered to operate in extended temperature ranges and to provide balanced data transmission lines for robust communication in industrial environments.

Key Features:

  • Low Power Operation: The LTC485CS8#TR is optimized for low power consumption, making it suitable for battery-powered and power-sensitive applications.
  • High Data Rates: Capable of supporting data rates up to 2.5Mbps, this transceiver can handle high-speed data transmission with ease.
  • Extended Temperature Range: Its industrial-grade design allows it to operate reliably in extreme temperatures ranging from -40°C to 85°C.
  • Single 5V Supply: The device operates from a single 5V supply, simplifying power supply design and management.
  • Thermal Shutdown Protection: Built-in thermal shutdown protection prevents damage from overheating, enhancing the transceiver's reliability and lifespan.
  • Pin-Compatible Upgrades: The LTC485CS8#TR is designed to be pin-compatible with several other Linear Technology transceivers, allowing for easy upgrades and design iterations.

Applications:

  • Industrial Control Systems
  • Networked Devices in Harsh Environments
  • Data Acquisition Systems
  • Building Automation
  • Security Systems

The LTC485CS8#TR is available in an 8-lead SOIC package, which is suitable for automated assembly processes and compact PCB layouts. Its tape and reel packaging (indicated by the #TR suffix) makes it ideal for high-volume production.

With its robust feature set and Linear Technology's reputation for high-quality components, the LTC485CS8#TR is a reliable choice for engineers looking to implement RS485 or RS422 communication in their designs, particularly where power efficiency and reliability in tough conditions are paramount.
