Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Series μModule
Packaging Tray
Battery Chemistry Multi-Chemistry
Number of Cells 1
Current - Charging Constant
Programmable Features Timer
Charge Current - Max 2.1A
Voltage Supply MAX 32V
Operating Temperature Range -40°C ~ 125°C (TA)
Package 77-BLGA
Manufacturer Package 77-LGA (15x9)
Win Source Part Number 784648-LTM8062EV#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTM8062
Introduction Date August 23, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTM8062EV#PBF CAD Model

Description

The LTM8062EV#PBF is a high-performance step-down μModule (micromodule) regulator from Linear Technology, now part of Analog Devices. This comprehensive power management IC integrates a switching regulator, inductors, and support components into a compact, encapsulated package, designed to simplify the implementation of power conversion in a wide range of applications.

Key Features

  • Integrated Solution: The LTM8062EV#PBF combines a high-efficiency synchronous step-down DC/DC converter with onboard inductors, power switches, a data acquisition system, and control circuitry, all housed in a space-efficient package.
  • Wide Input Voltage Range: This μModule regulator can accept an input voltage range of 6V to 58V, making it versatile for use in various systems that experience wide input voltage variations.
  • Adjustable and Fixed Output: Users can set the output voltage from 0.8V to 10V via an external resistor, or they can opt for fixed output voltage versions to meet specific design requirements.
  • High Efficiency: With its synchronous rectification topology, the LTM8062EV#PBF offers high conversion efficiency, which is critical for thermal management and energy savings in power-sensitive applications.
  • Compact Footprint: The compact LGA package (9mm x 15mm x 4.32mm) saves precious board space and is suitable for systems where space is at a premium.
  • Protection Features: It includes overvoltage, overcurrent, and overtemperature protection, ensuring reliable operation under abnormal conditions.

Applications

The LTM8062EV#PBF is ideal for use in a variety of applications including but not limited to industrial controls, automotive systems, telecommunications equipment, and distributed power systems. Its robust design and ease of use make it a go-to choice for engineers looking for a quick and reliable power solution.

Quality and Reliability

Linear Technology's products are known for their high quality and reliability, and the LTM8062EV#PBF is no exception. This μModule regulator is designed to meet stringent performance standards, ensuring consistent operation even in challenging environments.

Ordering Information

The LTM8062EV#PBF is available in a RoHS-compliant LGA package, ensuring environmental compliance for global use. For detailed product specifications, technical documentation, and ordering information, please refer to the Linear Technology/Analog Devices official website or contact their sales and support team.
