Products specifications Report Issue?

RoHS State Request Verification
Manufacturer LSI Computer Systems
Win Source Part Number 1204589-LS7060
Manufacturer Homepage www.lsicsi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LS7060 CAD Model

Description

The LS7060 is a quadrature clock converter manufactured by LSI Computer Systems. It is designed to convert quadrature encoder signals into clock and direction signals, simplifying interface requirements for microcontrollers and other digital systems. This converter is commonly used in applications involving rotary encoders, linear scales, and other position sensing devices.

Applications

  • Rotary encoder interfaces
  • Linear scale interfaces
  • Position sensing systems
  • Motor control systems
  • Robotics

Features

  • Quadrature clock conversion: Converts A/B quadrature signals into clock and direction outputs.
  • Single-chip solution: Integrates all necessary logic for quadrature decoding.
  • High noise immunity: Minimizes errors due to noisy environments.
  • TTL compatible outputs: Easy interface with standard logic circuits.
  • Simple interface: Simplifies the connection between encoders and microcontrollers.

Benefits

  • Simplified system design by reducing the complexity of quadrature decoding.
  • Improved reliability in noisy environments due to high noise immunity.
  • Easy integration with existing digital systems using TTL compatible outputs.
  • Reduced development time and cost by providing a complete quadrature decoding solution.
  • Enhanced system performance through accurate and reliable position tracking.

Additional Details

The LS7060 typically operates from a single 5V power supply and is available in a variety of package options, including DIP and SOIC. It accepts two quadrature input signals (A and B) and generates clock and direction outputs that can be directly connected to a microcontroller or other digital system. The direction output indicates the direction of movement, while the clock output provides a pulse for each increment of movement. The device also includes built-in hysteresis to improve noise immunity and prevent false triggering.

The LS7060 is commonly used in applications where precise position feedback is required, such as motor control systems, robotics, and industrial automation. Its ease of use and reliability make it a popular choice for both hobbyists and professional engineers. Proper grounding and decoupling techniques should be used to minimize noise and ensure stable operation. The datasheet provides detailed information on the device's electrical characteristics, timing diagrams, and application circuits.
