Products specifications

RoHS State Request Verification
Manufacturer Macronix
Win Source Part Number 1228844-MX29F016TC-12
Manufacturer Homepage www.macronix.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MX29F016TC-12 CAD Model

Description

The MX29F016TC-12 is a 16 Mbit Flash memory device manufactured by Macronix. It is organized as 2M x 8 bits and features a fast access time. This memory device is commonly used in embedded systems for storing firmware, boot code, and data, providing a non-volatile storage solution.

Applications:

  • Embedded systems: Storing firmware, boot code, and configuration data in microcontrollers and microprocessors.
  • Networking equipment: Used in routers, switches, and modems for storing network protocols and configuration settings.
  • Industrial control systems: Providing non-volatile memory for programmable logic controllers (PLCs) and other industrial devices.
  • Consumer electronics: Storing firmware in set-top boxes, digital TVs, and gaming consoles.
  • Automotive electronics: Used in automotive control units (ECUs) for storing calibration data and software updates.

Features:

  • 16 Mbit (2M x 8) capacity: Provides ample storage space for code and data.
  • Fast access time (120ns): Enables quick read operations.
  • Single 5V power supply: Operates on a single voltage supply, simplifying system design.
  • Sector Erase: Allows for selective erasing of memory sections.
  • Chip Erase: Allows for erasing the entire memory array.
  • Write Protection: Prevents accidental overwriting of data.
  • CMOS process: Low power consumption for battery-powered applications.

Benefits:

  • Non-volatile storage: Retains data even when power is removed.
  • Fast read access: Quick access time improves system responsiveness.
  • Easy integration: Simple interface simplifies integration with microcontrollers and other devices.
  • Reliable data storage: Offers reliable data retention capabilities.
  • Cost-effective: Provides a cost-efficient storage solution.

Additional Details:

The MX29F016TC-12 operates across a range of temperatures, commonly from -40°C to +85°C. It's available in a variety of packages such as TSOP and PLCC. The device requires specific timing and voltage levels for write and erase operations, detailed in its datasheet. The datasheet also provides information on data retention and endurance characteristics.

The MX29F016TC-12 is suitable for applications requiring reliable non-volatile memory with fast access times. Its features and performance make it a useful component in many embedded systems and electronic devices.
