Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Microchip Technology
Package Bulk
Product Status Active
Voltage - Zener (Nom) (Vz) 11 V
Tolerance ±5%
Power - Max 500 mW
Impedance (Max) (Zzt) 22 Ohms
Current - Reverse Leakage @ Vr 2 µA @ 8 V
Voltage - Forward (Vf) (Max) @ If 1.5 V @ 200 mA
Temperature Range - Operating -65°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case DO-204AH, DO-35, Axial
Supplier Device Package DO-35 (DO-204AH)
Standard Package 1 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 539188-1N5241
Ultra Librarian 3D Model Ultra Librarian 1N5241 CAD Model

Description

Product Overview: 1N5241 Zener Diode from Microchip Technology

The 1N5241 is a high-quality Zener diode crafted by the renowned manufacturer Microchip Technology. This electronic component is designed to provide precise voltage regulation, making it an essential part of various electronic circuits. The 1N5241 operates as a voltage regulator by allowing current to flow in the reverse direction when a specific voltage threshold is reached, known as the Zener voltage.

Key Features

  • Voltage Regulation: With a Zener voltage of 11V, the 1N5241 ensures stable and reliable voltage regulation, which is vital for sensitive electronic components.
  • Power Dissipation: It has a power dissipation rating of 500mW, which allows it to handle moderate levels of power without overheating or failing.
  • Package: This diode comes in a DO-35 package, which is a small and durable glass package widely used for through-hole mounting on printed circuit boards (PCBs).
  • Operating Temperature Range: The 1N5241 can operate within a temperature range of -65°C to +200°C, making it suitable for a variety of challenging environments.
  • Reverse Leakage Current: It has a low leakage current, ensuring that the power consumption remains minimal when the diode is in the off state.

Applications

The 1N5241 Zener diode from Microchip Technology is commonly used in a variety of applications, including:

  • Power supply regulation
  • Overvoltage protection
  • Voltage reference in analog circuits
  • Surge suppression in electronic devices

Microchip Technology's commitment to quality ensures that the 1N5241 Zener diode is a reliable choice for designers and engineers looking to incorporate voltage regulation and protection in their electronic designs. Its precise voltage control and robustness make it a versatile component suitable for a wide range of electronic applications.

Ordering Information

For those interested in integrating the 1N5241 into their projects, it can be ordered through Microchip Technology's official distributors or directly from their website. The product is available in various pack sizes to accommodate different production volumes.
