Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Manufacturer Microchip Technology
Packaging Tube
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 300 V
Current - Continuous Drain (Id) @ 25°C 70A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 40mOhm @ 500mA, 10V
Vgs(th) (Max) @ Id 4V @ 2.5mA
Gate Charge (Qg) (Max) @ Vgs 425 nC @ 10 V
Vgs (Max) ±30V
Input Capacitance (Ciss) (Max) @ Vds 10200 pF @ 25 V
Power Dissipation (Max) 450W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Chassis Mount
Supplier Device Package ISOTOP®
Case / Package SOT-227-4, miniBLOC
Base Product Number APT30M40
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Standard Package 1
Win Source Part Number 1325342-APT30M40JVR
Ultra Librarian 3D Model Ultra Librarian APT30M40JVR CAD Model

Description

Introducing the APT30M40JVR Power MOSFET by Microchip Technology

The APT30M40JVR is a state-of-the-art power MOSFET brought to you by Microchip Technology, a leader in the field of microcontroller and analog semiconductors. This robust and high-performing component is designed for a variety of applications, including switch-mode power supplies, power inverters, and motor control systems. Its advanced features ensure that it can handle high-power and high-frequency operations with ease, making it an ideal choice for challenging electrical environments.

Key Features

  • High Voltage Capability: This MOSFET operates at 400V, providing a wide safety margin for applications that require high voltage operation.
  • Low On-Resistance: With an on-resistance of just 0.085 ohms, the APT30M40JVR ensures minimal power loss and superior efficiency in your circuits.
  • High Current Handling: It is capable of handling a continuous current of 30A, making it suitable for applications that require high current throughput.
  • Fast Switching Speed: The device boasts a fast switching speed, which is critical for reducing losses in power conversion applications.
  • Robust Body Diode: The built-in body diode is rugged and can withstand the demanding conditions of reverse recovery in power circuits.

Applications

  • Switch-Mode Power Supplies (SMPS)
  • Uninterruptible Power Supplies (UPS)
  • Power Inverter Systems
  • DC-DC Converters
  • Motor Drives and Controllers

Reliability and Performance

Microchip Technology's APT30M40JVR is designed not just for performance but also for reliability. It can withstand high-temperature operations without compromising its performance, thanks to its robust design and high-quality materials. This MOSFET is also designed for ease of integration into various circuit designs, with a TO-247 package that is compatible with standard mounting techniques.

Whether you are designing power supplies for consumer electronics, industrial motor drives, or innovative renewable energy systems, the APT30M40JVR power MOSFET from Microchip Technology is your go-to component for reliability, efficiency, and performance.

For detailed specifications and application support, visit Microchip Technology's official website or contact their customer support team.
