Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Obsolete(EOL)
Memory Format FLASH
Technology FLASH
Memory Size 4Mb (264 Bytes x 2048 pages)
Max Frequency 66MHz
Supply Voltage - Operating 2.7 V to 3.6 V
Temperature Range - Operating -40°C to 85°C (TC)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 091566-AT45DB041D-SU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AT45DB041D
Introduction Date October 01, 2012
ECCN 3A991
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian AT45DB041D-SU CAD Model

Description

Microchip Technology AT45DB041D-SU Overview

The AT45DB041D-SU is a 4-megabit, serial-interface Flash memory device ideally designed for a wide variety of digital voice-, image-, program code- and data-storage applications. Manufactured by Microchip Technology, this high-density, low-power DataFlash® offers a robust storage solution for compact systems where space is at a premium.

Key Features

  • Capacity: The device features 4Mb of memory space which is organized as 2,048 pages of 256 bytes each.
  • Serial Interface: It provides a simple and flexible serial interface that is SPI-compatible for easy integration with most microcontrollers.
  • Enhanced Data Integrity: This memory module includes an internal error correction algorithm to ensure data integrity during read operations.
  • Low-power Consumption: Designed for battery-powered devices, the AT45DB041D-SU offers low-power consumption in both active and standby modes.
  • Flexible Erase Options: The device supports sector and block erase functions, allowing for efficient memory management and conservation.
  • High-speed Operation: It is capable of a rapid read/write performance that ensures swift data handling in critical applications.

Applications

The AT45DB041D-SU is versatile in its applications, suitable for use in digital voice recorders, MP3 players, digital cameras, and other devices that require high-speed, reliable data storage. Its robust design also makes it an excellent choice for industrial applications where long-term data retention is crucial.

Package and Temperature Range

The device is available in an 8-lead SOIC (AT45DB041D-SU) package, providing a compact footprint for space-constrained applications. It operates across an industrial temperature range, ensuring reliable performance under varying environmental conditions.

With its combination of features, the AT45DB041D-SU from Microchip Technology stands out as a solid choice for designers looking for a non-volatile memory solution with a balance of performance, reliability, and cost-effectiveness.
