Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Number of I/O 8
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 25mA
Max Frequency 1.7MHz
Supply Voltage - Operating 1.8 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 20-QFN-EP (4x4)
Win Source Part Number 091622-MCP23008T-E/ML
Family Name MCP23008
Introduction Date December 16, 2004
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MCP23008T-E/ML CAD Model

Description

Microchip Technology MCP23008T-E/ML Overview

The MCP23008T-E/ML is a versatile 8-bit I/O expander from Microchip Technology, designed to provide additional input/output (I/O) ports for microcontrollers via the two-wire I²C-compatible serial interface. This compact, surface-mount device is part of Microchip's MCP23008 series and comes in a 16-lead QFN (ML) package, making it suitable for space-constrained applications.

The MCP23008T-E/ML offers a convenient solution for applications that require additional I/Os or where I/O pins on the microcontroller are limited. It is particularly useful in applications such as home automation, industrial control, and automotive systems where the expansion of I/Os can significantly enhance the functionality of the system.

Key Features

  • Interface: I²C-compatible serial interface that operates at clock frequencies up to 400 kHz, allowing for easy integration with most microcontrollers.
  • Ports: Eight individually addressable I/Os that can be configured as an input or output, providing flexibility in controlling external devices.
  • Interrupt Output: An interrupt output pin can be configured to alert the host microcontroller when an input state has changed, improving system responsiveness and efficiency.
  • Input Polarity Inversion: The ability to invert the polarity of the input port data without affecting the actual pin state, which simplifies software data management.
  • Addressing: Three hardware address pins to configure up to eight devices on the same bus, allowing for up to 64 I/Os on a single I²C bus.
  • Operating Voltage: Supports a wide range of supply voltages from 2.7V to 5.5V, accommodating various logic levels and power supplies.
  • Extended Temperature Range: The device is rated for operation over the extended temperature range of -40°C to +125°C, ensuring reliable performance in harsh environments.

Applications

The MCP23008T-E/ML is ideal for expanding I/O capabilities in a broad array of applications, including but not limited to:

  • Remote I/O
  • Sensor interfacing
  • Power management
  • Industrial control systems
  • Home automation systems
  • Automotive electronics

By integrating the MCP23008T-E/ML into your design, you can enhance the I/O capability of your system with minimal impact on the size and complexity of your PCB layout.
