Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 0.15 V/μs
Gain Bandwidth Product (GBP) 300kHz
Current - Input Bias 1pA
Voltage - Input Offset 5mV
Operating Supply Current 20μA
Channel Output Current 23mA
Supply Voltage - Operating 1.8 V to 6 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 058366-MCP6232-E/SN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MCP6232
Introduction Date August 16, 2004
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Not Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian MCP6232-E/SN CAD Model

Description

The MCP6232-E/SN is a high-precision operational amplifier (op-amp) introduced by Microchip Technology, a leader in the field of smart, connected, and secure embedded control solutions. This particular model is part of the MCP6232 family, which is known for its low power consumption and general-purpose nature, making it suitable for a wide range of applications.

Key Features

  • Dual Amplifier: The MCP6232-E/SN features two independent op-amps in a single package, providing flexibility in design for various analog circuit applications.
  • Supply Voltage: It operates at a single supply voltage ranging from 1.8V to 6.0V or a dual supply voltage of ±0.9V to ±3.0V, catering to low-voltage operation requirements.
  • Low Quiescent Current: With a quiescent current of just 20 µA, it is optimized for low-power applications, contributing to energy efficiency in battery-powered devices.
  • Extended Temperature Range: The device is designed to perform reliably in a wide temperature range from -40°C to +125°C, making it suitable for industrial and automotive applications.
  • Rail-to-Rail Input/Output: The MCP6232-E/SN offers rail-to-rail input and output swing, which maximizes the dynamic range in low-voltage applications.
  • Gain Bandwidth Product: It has a gain bandwidth product of 300 kHz, which is adequate for low-frequency signal amplification.
  • Package: The device comes in an 8-pin SOIC package, which is a small outline package that is easy to integrate into PCB designs.

Applications

The versatility of the MCP6232-E/SN operational amplifier allows it to be used in a variety of applications, including:

  • Portable instrumentation
  • Battery-powered devices
  • Analog filters
  • Sensor amplification
  • Data acquisition systems

In conclusion, the MCP6232-E/SN from Microchip Technology is an ideal choice for designers looking for a low-power, dual operational amplifier with a broad operating temperature range and rail-to-rail input/output capabilities. Its compact form factor and power efficiency make it an excellent option for a myriad of electronic applications.
