Products specifications

Category Integrated Circuits (ICs) - Interface - Sensor and Detector Interfaces
Mfr Microchip Technology
Package Tube
Type Thermocouple to Digital Converter
Input Type Thermocouple
Output Type I2C
Current - Supply 300 µA
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 20-VQFN Exposed Pad
Supplier Device Package 20-MQFN (5x5)
Base Product Number MCP96RL00
Standard Package 73
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1340447-MCP96RL00-E/MX
Ultra Librarian 3D Model Ultra Librarian MCP96RL00-E/MX CAD Model

Description

The MCP96RL00-E/MX from Microchip Technology is a sophisticated thermocouple-to-digital converter integrated circuit that is designed to deliver precise temperature measurements with a direct digital output. This high-performance device is an ideal solution for a wide range of temperature sensing applications, from industrial systems to consumer products.

At the heart of the MCP96RL00-E/MX lies a robust thermocouple EMF (Electromotive Force) to degree Celsius converter, which is capable of interpreting the millivolt signals generated by a thermocouple. It then converts these signals into a temperature reading with a resolution of 0.1°C. The device supports a variety of thermocouple types, including K, J, T, N, S, E, B, and R, providing flexibility to match different measurement requirements.

One of the key features of the MCP96RL00-E/MX is its built-in cold junction compensation. This is critical for maintaining accuracy, as it adjusts the temperature reading to account for the temperature difference between the thermocouple junction and the IC itself. Additionally, the device offers a high level of noise immunity and is designed to operate in harsh environments, where temperatures can range from -40°C to +125°C.

Communication with the MCP96RL00-E/MX is facilitated through an SPI (Serial Peripheral Interface), allowing for easy integration into a microcontroller-based system. The device also includes fault detection capabilities, which can signal if the thermocouple is open, shorted, or operating outside of its specified range. This ensures reliable and safe operation in critical applications.

The MCP96RL00-E/MX comes in a compact, surface-mount package, making it suitable for space-constrained applications. With its precision temperature measurement, robust design, and versatile interface options, the MCP96RL00-E/MX from Microchip Technology is a top-tier component for any temperature monitoring and control system.
