Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Type 555 Type, Timer/Oscillator (Single)
Frequency 5MHz
Supply Voltage - Operating 2.7 V to 18 V
Operating Supply Current 350μA
Temperature Range - Operating -40°C to 85°C
Case / Package SOT-23-5
Mounting Surface Mount
Win Source Part Number 038381-MIC1555BM5
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MIC1555BM5 CAD Model

Description

Microchip Technology's MIC1555BM5: A Compact Timing Solution

The MIC1555BM5 from Microchip Technology is a versatile, miniature timer IC that offers a wide range of timing capabilities in a compact SOT-23-5 package. Designed to meet the needs of a variety of applications, this precision timer is capable of producing accurate time delays or frequencies.

Key Features

  • Adjustable Timing: The MIC1555BM5 allows for user-adjustable timing settings that can generate delays from microseconds to hours, making it incredibly versatile for different applications.
  • Low Power Consumption: This IC is optimized for low power consumption, which is ideal for battery-powered devices and applications where energy efficiency is crucial.
  • Supply Voltage Range: It operates over a supply voltage range of 2.7V to 18V, providing flexibility in various power environments.
  • High Frequency Operation: Capable of operating at frequencies up to 5MHz, the MIC1555BM5 is suitable for high-speed applications.
  • Temperature Stability: The timer maintains stable operation over a temperature range of -40°C to +85°C, ensuring reliability in diverse environments.
  • Simple External Components: Requiring only an external resistor and capacitor to set the timing intervals, this IC is easy to implement into designs.

Applications

The MIC1555BM5 is an ideal choice for a broad range of applications, including:

  • Precision timing
  • Pulse generation
  • Sequential timing
  • Time delay generation
  • Frequency division
  • Battery-powered devices

Why Choose MIC1555BM5?

Engineers and designers opt for the MIC1555BM5 for its compact size, ease of use, and the reliability that comes with the Microchip Technology name. Its SOT-23-5 package makes it an excellent choice for space-constrained applications. Whether it's used in consumer electronics, automotive systems, or industrial controls, the MIC1555BM5 delivers precise timing solutions in a tiny footprint.
