Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type P-Channel
Voltage - Load 2.5 V to 5.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 2A
Rds On (Typ) 70 mOhm
Input Type Non-Inverting
Features Load Discharge, Slew Rate Controlled
Fault Protection Current Limiting (Adjustable), Over Temperature
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package SOT-23-6
Win Source Part Number 092741-MIC2007YM6
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MIC2007YM6 CAD Model

Description

Microchip Technology MIC2007YM6 Power Distribution Switch

The MIC2007YM6 from Microchip Technology is a sophisticated power distribution switch designed for applications where power management is critical. This compact component belongs to Microchip's family of high-side power switches, which are specifically engineered to control power to downstream USB devices, peripherals, and other digital systems.

Key Features:

  • Integrated Power Switch: The MIC2007YM6 features an integrated 140mΩ high-side N-channel MOSFET that provides efficient power switching with minimal voltage drop.
  • Current Limiting: To protect against overcurrent conditions, the device offers programmable current limiting, which ensures the safety of the power distribution system.
  • Thermal Shutdown: An in-built thermal shutdown function provides additional protection by turning off the switch in the event of excessive temperature rise.
  • Under-voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off if the input voltage drops below a certain threshold, preventing erratic behavior of the connected device.
  • Status Flag: An open-drain fault status output flag is available to indicate overcurrent, thermal shutdown, or under-voltage lockout conditions.
  • Low Quiescent Current: With its low standby current, the MIC2007YM6 is ideal for battery-powered applications where power conservation is a priority.

Applications:

  • USB Hubs and Peripherals
  • Hot-Swap Supplies
  • Notebook Computers
  • Portable Devices

The MIC2007YM6 comes in a small 6-pin 2mm x 2mm TDFN package, making it suitable for space-constrained applications. Its design is optimized for simplicity and ease of use, requiring minimal external components to function.

Overall, the MIC2007YM6 power distribution switch from Microchip Technology is an essential component for designers looking to incorporate reliable power management into their systems. Its protection features, low power consumption, and compact size make it an excellent choice for a wide range of electronic applications.
