Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type P-Channel
Voltage - Load 2.5 V to 5.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 2A
Rds On (Typ) 70 mOhm
Input Type Non-Inverting
Features Load Discharge, Slew Rate Controlled
Fault Protection Current Limiting (Adjustable), Over Temperature
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 6-MLF (2x2)
Win Source Part Number 115291-MIC2007YML-TR
Ultra Librarian 3D Model Ultra Librarian MIC2007YML-TR CAD Model

Description

Microchip Technology's MIC2007YML-TR Power Distribution Switch

The MIC2007YML-TR from Microchip Technology is a highly integrated power distribution switch designed to add sophistication and precision to your power management solutions. This component is part of Microchip's extensive range of power management products and is tailored to meet the demands of applications requiring power distribution and over-current protection.

The MIC2007YML-TR is a current-limiting device that provides a controlled and limited amount of current to downstream devices. This is particularly useful in situations where over-current conditions could potentially damage sensitive electronics. It is an ideal choice for USB ports, hot-swap applications, and other systems where power distribution needs to be managed carefully.

This power distribution switch operates with an input voltage range of 2.7V to 5.5V, which makes it versatile for various low-voltage applications. It features a 140mΩ on-resistance, which ensures minimal voltage drop and power loss across the switch, thereby enhancing the overall efficiency of the power management system.

The MIC2007YML-TR is equipped with thermal shutdown protection that safeguards the device and the system from excessive temperature rise. Additionally, the under-voltage lockout (UVLO) feature ensures that the switch remains off if the input voltage drops below a certain threshold, preventing erratic system behavior.

Furthermore, the device offers a fast short-circuit response time, limiting the duration of the over-current condition and reducing the risk of damage. It also has an auto-restart feature that attempts to reset the power after a fault condition, which can be invaluable in systems that require unattended recovery.

The MIC2007YML-TR comes in a compact 8-lead 2x2mm TML package, which is suitable for space-constrained applications. Its lead-free and RoHS-compliant design aligns with modern environmental standards, making it a responsible choice for eco-friendly designs.

In summary, the MIC2007YML-TR is a robust and reliable solution for managing power distribution in electronic systems. Its advanced features ensure protection and stability, making it a smart addition to any power-sensitive application.
