Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Switch Type USB Switch
Number of Outputs 1
Output Type N-Channel
Voltage - Load 2.7 V to 5.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 1.5A
Rds On (Typ) 80 mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Adjustable), Over Temperature
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 8-MSOP
Win Source Part Number 003482-MIC2544-2YMM
Family Name MIC2544
Introduction Date June 01, 2000
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MIC2544-2YMM CAD Model

Description

The MIC2544-2YMM is a high-performance integrated circuit designed and manufactured by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This device is part of Microchip's extensive portfolio of power management products and offers a robust solution for USB power management applications.

Key Features

  • Integrated USB Switch: The MIC2544-2YMM includes an integrated switch specifically designed for USB power distribution systems, providing a controlled and protected power supply to USB devices.
  • Programmable Current Limiting: This feature protects the USB port by preventing excessive current draw that can lead to system damage. The current limit is programmable, allowing for flexibility across different applications.
  • Thermal Shutdown Protection: The device is equipped with thermal shutdown protection, ensuring that it will automatically turn off if it exceeds a certain temperature threshold, thereby preventing thermal damage.
  • Under Voltage Lockout (UVLO): The MIC2544-2YMM has a built-in UVLO feature that ensures the device operates only when the input voltage is within its specified range, protecting both the IC and connected devices from low voltage conditions.
  • Fast Short-Circuit Response: In the event of a short circuit, the MIC2544-2YMM responds quickly to protect the circuitry from damage.
  • Low Standby Current: The device has a low standby current, which is ideal for battery-powered applications where power conservation is crucial.

Applications

The MIC2544-2YMM is well-suited for a variety of applications, including:

  • USB Hubs
  • Peripheral Power Management
  • Desktop and Notebook Computers
  • Consumer Electronics
  • Portable Device Docks

Package and Availability

The MIC2544-2YMM comes in a compact 8-pin MSOP (Mini Small Outline Package) that is both space-saving and suitable for automated assembly processes. The device is available through Microchip Technology's extensive distribution network, ensuring availability for both small-scale and large-volume production needs.

Conclusion

With its combination of USB power management features, programmable current limiting, thermal protection, and other safety features, the MIC2544-2YMM from Microchip Technology represents a reliable and versatile solution for designers looking to enhance the performance and safety of their USB power delivery systems.
