Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 25V
Dropout Voltage-Max 0.6V @ 5A
Output Current 5A
Operating Supply Current 50mA
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity, Transient Voltage
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 26 V
Voltage - Dropout (Typical) 0.37V @ 5A
Mounting SMD (SMT)
Case / Package TO-263-5
Win Source Part Number 087082-MIC29502WU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MIC29502WU CAD Model

Description

Product Overview: MIC29502WU from Microchip Technology

The MIC29502WU is a high-performance, adjustable output voltage regulator from Microchip Technology, designed to handle up to 5A of output current. This robust low-dropout linear regulator (LDO) is ideal for a wide range of applications, from automotive to industrial and consumer electronics, where reliability and efficiency are paramount.

The device features a wide input voltage range from 4.5V to 36V, making it suitable for systems that experience large variations in supply voltage. This flexibility ensures that the MIC29502WU can be used in environments with unstable power supplies or where battery voltage can fluctuate significantly.

One of the key advantages of the MIC29502WU is its low dropout voltage, which enhances efficiency by allowing the regulator to continue to operate even when the input-to-output voltage differential is minimal. This characteristic is particularly beneficial in battery-operated devices, where prolonging battery life is critical.

The output voltage of the MIC29502WU is adjustable, giving designers the flexibility to set the voltage to a desired level to meet the specific needs of their application. The output can be set from 1.25V to 26V with the use of external resistors, providing a versatile solution for powering a variety of loads.

Thermal regulation is another feature of the MIC29502WU, ensuring that the device remains within safe operating temperatures even under heavy load conditions. This is achieved through an integrated thermal shutdown mechanism, which protects the device from overheating and potential damage.

For additional protection, the MIC29502WU also includes current limit and short-circuit protection. These safety features safeguard the regulator and the downstream components from excessive current draw and potential short-circuit conditions.

In summary, the MIC29502WU from Microchip Technology is a reliable and efficient solution for applications requiring a high-current LDO with an adjustable output voltage. Its robust feature set and wide input voltage range make it an excellent choice for a myriad of demanding applications.
