Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Series PIC XLP 12F
Packaging Tube
Core Processor PIC
Core Size 8-Bit
Speed 32MHz
Connectivity I2C, LIN, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 6
Program Memory Size 3.5KB (2K x 14)
Program Memory Type FLASH
EEPROM Size 256 x 8
RAM Size 128 x 8
Supply Voltage 1.8 V ~ 5.5 V
Data Converters A/D 4x10b, D/A 1x5b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 125°C (TA)
Package 8-SOIC (0.154", 3.90mm Width)
Manufacturer Package 8-SOIC
Win Source Part Number 791877-PIC12F1822-E/SN
Popularity Medium
Supply and Demand Status Limited
Family Name PIC12F1822
Introduction Date March 05, 2010
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian PIC12F1822-E/SN CAD Model

Description

Microchip Technology PIC12F1822-E/SN Microcontroller

The PIC12F1822-E/SN is a powerful 8-bit microcontroller from the renowned manufacturer, Microchip Technology. This compact yet robust component comes in an 8-pin SOIC package, making it an excellent choice for space-constrained applications. It is well-suited for a variety of electronic projects and commercial products, ranging from simple DIY projects to complex industrial systems.

The device operates with a standard voltage range of 2.5V to 5.5V, which allows for flexible power management and compatibility with a wide range of peripherals and power sources. The PIC12F1822-E/SN features a high-performance RISC CPU, providing a maximum speed of 32MHz. This ensures swift processing capabilities which are essential for time-sensitive tasks and applications requiring quick data processing and real-time responses.

Embedded within the microcontroller is 3.5KB of flash memory, which is ample for storing application code. Additionally, it includes 128 bytes of EEPROM and 256 bytes of RAM, offering sufficient storage for data handling and manipulation. The device also incorporates several peripherals that enhance its functionality, such as an internal oscillator, multiple timers, and communication modules like I2C, SPI, and UART for versatile connectivity options.

One of the standout features of the PIC12F1822-E/SN is its integrated 10-bit Analog-to-Digital Converter (ADC), which allows the microcontroller to interface with analog sensors and devices directly. This feature is particularly useful for applications that require precise sensor readings or analog signal processing.

Furthermore, the microcontroller supports various programming and debugging methods, including In-Circuit Serial Programming™ (ICSP™) and In-Circuit Debug (ICD). These features allow developers to program the device easily and troubleshoot it within the application circuit, significantly reducing development time and increasing productivity.

In summary, the PIC12F1822-E/SN from Microchip Technology is a versatile, feature-rich microcontroller that offers a balance between performance and size. Its extensive set of built-in peripherals and programming capabilities make it an ideal choice for engineers and hobbyists seeking a reliable and efficient solution for their embedded systems.
