Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Series PIC XLP 18K
Packaging Tray
Core Processor PIC
Core Size 8-Bit
Speed 64MHz
Connectivity ECAN, I2C, LIN, SPI, UART/USART
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Number of I/O 35
Program Memory Size 64KB (32K x 16)
Program Memory Type FLASH
EEPROM Size 1K x 8
RAM Size 3.6K x 8
Supply Voltage 1.8 V ~ 5.5 V
Data Converters A/D 11x12b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 125°C (TA)
Package 44-TQFP
Manufacturer Package 44-TQFP (10x10)
Win Source Part Number 792110-PIC18F46K80-E/PT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name PIC18F46K80
Introduction Date January 27, 2011
ECCN 3A991.a.2
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian PIC18F46K80-E/PT CAD Model

Description

Microchip Technology's PIC18F46K80-E/PT Microcontroller

The PIC18F46K80-E/PT is a high-performance microcontroller unit (MCU) from the reputable manufacturer Microchip Technology. This MCU is part of the PIC18F K80 family, which is specifically engineered to offer a balance between power consumption and functionality, making it an ideal choice for a wide range of applications, including automotive systems, industrial control, and consumer electronics.

Key Features:

  • Core: The device features a powerful PIC18 core with an operating speed of up to 64 MHz, providing robust processing capabilities for complex tasks.
  • Memory: It comes with 64 KB of flash memory and 3,648 bytes of RAM, ensuring ample space for program storage and efficient data management.
  • I/O Pins: With 36 I/O pins, this MCU offers flexibility in interfacing with various peripherals and electronic components.
  • Communication Peripherals: It includes multiple communication interfaces such as CAN (Controller Area Network), SPI (Serial Peripheral Interface), I2C, and USART, allowing for versatile connectivity options.
  • Analog Features: The device boasts a 12-bit Analog-to-Digital Converter (ADC) with up to 16 channels, enabling precise analog signal measurement and conversion.
  • Temperature Range: Operating within an extended temperature range, this MCU is suitable for environments with temperatures ranging from -40°C to +125°C.
  • Power Management: Enhanced power management features include nanoWatt technology, which provides different power-saving modes to reduce overall power consumption.
  • Packaging: The PIC18F46K80-E/PT is available in a 44-pin TQFP (Thin Quad Flat Pack) package, ensuring a compact footprint for space-constrained applications.

Applications:

The versatility of the PIC18F46K80-E/PT MCU makes it suitable for a multitude of applications. It is commonly used in automotive applications for engine control, body control modules, and in-vehicle networking. Additionally, it is well-suited for industrial automation, such as in sensor nodes, control systems, and communication gateways. Consumer electronics, including smart home devices and portable electronics, also benefit from the integration of this reliable MCU.

Overall, the PIC18F46K80-E/PT from Microchip Technology is a robust and feature-rich microcontroller that offers designers the perfect balance of performance and power efficiency for their embedded system projects.
