Products specifications

Category Integrated Circuits (ICs) - Interface - Specialized
Mfr Microchip Technology
Package Tray
Product Status Active
Applications Controller
Interface LPC
Voltage - Supply 3.3V
Package / Case 128-TQFP
Supplier Device Package 128-VTQFP (14x14)
Mounting Type Surface Mount
Base Product Number SCH3116
Standard Package 90 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.39.0001
Win Source Part Number 511645-SCH3116I-NU
Ultra Librarian 3D Model Ultra Librarian SCH3116I-NU CAD Model

Description

Microchip Technology's SCH3116I-NU Super I/O Controller

The SCH3116I-NU is a versatile and high-performance Super I/O (Input/Output) controller developed by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. Designed to cater to the needs of modern embedded systems, the SCH3116I-NU integrates a variety of I/O functions that are essential for motherboard and embedded system designs.

This Super I/O controller features a wide range of capabilities including a keyboard controller with PS/2 mouse support, a full IEEE 1284-compliant parallel port, and a serial port with support for IrDA, ASKIR, and Consumer IR. The inclusion of these interfaces makes the SCH3116I-NU a comprehensive solution for systems requiring legacy I/O support.

One of the key advantages of the SCH3116I-NU is its flexibility. It is equipped with a Low Pin Count (LPC) interface, ensuring easy integration with modern chipsets and processors. This interface minimizes the number of pins required, which can be crucial for reducing overall system costs and complexity. Additionally, the device includes an enhanced digital data separator for floppy disk drives, with support for 1 Mbps transfer rates, which is particularly beneficial for industrial and legacy applications that still rely on floppy media.

The SCH3116I-NU also comes with an array of embedded control functionalities, such as hardware monitoring capabilities that allow for system health monitoring. This includes temperature, voltage, and fan speed monitoring, which are critical for ensuring the reliability and stability of the system.

With its robust design and extensive feature set, the SCH3116I-NU is ideal for a wide range of applications, including industrial PCs, servers, point-of-sale systems, and embedded control platforms. Its ability to support multiple legacy I/O functions makes it a go-to choice for system designers looking to maintain compatibility with existing peripherals while benefiting from the performance and efficiency of modern hardware.

Overall, the SCH3116I-NU from Microchip Technology stands out as a highly integrated and efficient solution for managing I/O in a variety of embedded systems, ensuring seamless operation and connectivity for legacy and contemporary applications alike.
