ADE-1+ Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category RF and Wireless - RF Mixers
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
RF Type VHF/UHF
Frequency 500kHz ~ 500MHz
Mounting Type Surface Mount
Package / Case 6-SMD, Flat Leads
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 816680-ADE-1+
Ultra Librarian 3D Model Ultra Librarian ADE-1+ CAD Model

Description

The Mini-Circuits 816680-ADE-1+ is an RF Mixer designed for VHF/UHF applications manufactured by Mini-Circuits.

  • Frequency Range: 500kHz to 500MHz
  • Package: 6-SMD, flat leads
  • Mounting: Surface Mountable
  • Standard Package: 1,000 pieces
  • Category: RF and Wireless
  • Applications: Communication systems, radar systems, electronic warfare systems
  • Noise Figure: Low
  • Gain: High
  • Status: Active
