90130-1208 Real Image
Same model may have multiple batches, images only for reference.

90130-1208

Part No 90130-1208
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn RJ-45 F 96 POS 2.54mm Solder RA Thru-Hole 96 Terminal 12 Port Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Material Brass, Copper
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin SK
Current Rating 3 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Polyester
Insulation Resistance 5 GΩ
Lead Free Yes
Lead Pitch 2.54 mm
Material Glass, Polyester
Maximum Operating Temperature 125 °C
Max Voltage Rating (DC) 350.35 kV
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 8
Number of Contacts 8
Number of Pins 8
Number of Poles 8
Number of Positions 8
Number of Rows 2
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Working Voltage 350 V
Win Source Part Number 1010793-90130-1208
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90130-1208 CAD Model

Description

The 1010793-90130-1208 is a male circular connector housing manufactured by Molex, LLC.

  • Gender: Male
  • Positions: 8
  • Rows: 2
  • Pitch: 2.54 mm
  • Voltage Rating: 350 V
  • Current Rating: 3 A
  • Contact Material: Brass and Copper
  • Contact Plating: Gold
  • Housing Material: Polyester
  • Housing Color: Black
  • Mounting: Through-Hole
  • Contact Resistance: 20 mΩ
  • RoHS: Compliant
  • Maximum Operating Temperature: 125°C
  • Packaging: Tape and Reel
  • Standard Package: 1,000
