Product Overview: 74HCT86D by NXP Semiconductors

The 74HCT86D is a high-speed Si-gate CMOS device from NXP Semiconductors, renowned for its reliability and performance in digital logic operations. This integrated circuit is part of the 74HCT series, which is compatible with TTL levels and designed to meet the requirements of high-speed and low-power consumption in modern electronic systems.

Key Features

• Logic Type: The 74HCT86D is a quad 2-input exclusive OR (XOR) gate, providing the essential function for parity generation and comparison, as well as various arithmetic and logical operations.
• Operating Voltage: It operates at a recommended voltage of 5V, which is suitable for interfacing with traditional 5V TTL logic while offering the benefits of CMOS technology, such as reduced power consumption.
• High-Speed Performance: The device boasts a typical propagation delay of 8ns, ensuring swift response times in critical applications.
• Power Consumption: With a low power dissipation of 2 µA (max) at 25°C, the 74HCT86D is ideal for power-sensitive designs.
• Output Capability: It can drive up to 10 LSTTL loads, providing ample current for downstream digital logic circuits.
• Package: The 74HCT86D comes in a SO14 package, which is a small-outline package that is both space-efficient and suitable for automated surface-mount assembly processes.

Applications

The versatility of the 74HCT86D makes it well-suited for a variety of applications, including:

• Logic comparison circuits
• Error detection and correction systems
• Binary arithmetic systems
• Signal gating
• Encryption and security devices

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The 74HCT86D is subjected to rigorous testing and quality control measures, ensuring that it meets the stringent standards required for industrial and commercial use. Its robust design is capable of withstanding the demands of high-performance environments, making it a reliable choice for designers and engineers alike.

With its combination of speed, efficiency, and versatility, the 74HCT86D from NXP is an excellent choice for any project requiring high-speed logic operations with minimal power consumption.
